Kollewin 19″TFT LCD Industrial touch panel PC:KW-P3819HT-D525

Kollewin 19″TFT LCD Industrial touch panel PC:KW-P3819HT-D525

Shell:Professional IP65 grade brushed aluminum alloy panel, heavy steel shock box, vacuum dust cooling system;
Display:Touch 19″TFTIndustrial grade highlighted,1280*1024,Support asynchronous VGA+LCD display;
Installation:support panel flush mounting,VESA 75 installation,VESA 100 installation;
Dimensions:Dimensions=466*370*90(W*H*D),Hole size=443*352(W*H);
System Security: programmable hardware watchdog protection system security and stability of 7 * 24 hours continuous operation;

Main Chipset:Intel Atom D525+NM10,Onboard Intel Atom D525 processor;

Vedio:High-speed graphics engine Intel GMA3150, DVMT memory support to 224MB;
Ethernet:Two high-speed Gigabit Industrial Ethernet adapter support PXE and WOL, RJ45 port;
Audio:ALC662 HD Audio Codec (Line_out;Mic_in);
Interface:7个RS-232,1 x RS-232/485,6 x USB2.0;1 x LPT port; Expansion Slots:One PCI expansion slot;
Power:12VDC(or 9~18VDC wide voltage input;);
Temperature: Operating Temperature -10 ℃ ~ 60 ℃, Storage temperature -40 ℃ ~ 80 ℃;
Applications: 7 * 24 hours of uninterrupted work in harsh environments (high dust, high temperature, complex electromagnetic environment);

Acceptable customized for OEM or ODM custom production

CPU:Intel Dual-core Atom D525 1.8GHz Dual-core, four threads, 64-bit processors;
System memory:Dual-channel DDR3 2GB(Can be customized);
System Storage:250GB SATAII 2.5″Hard Disk(Can be customized);
