6ES7441-2AA03-0AE0 SIMATIC S7-400, CP 441-2

0 reviews | Write a review

Product Code: 6ES7441-2AA03-0AE0

Availability: In Stock

Price: $1,006.95

Qty:

Add to Wish List

Add to Compare

Description
Reviews (0)

Artikelnummer

6ES7441-2AA03-0AE0


Input current
Interface modules
● 20 mA (TTY), power consumption from 5 V/24 V, max.		300 mA at 5 V, 45 mA at 24 V
● RS 422/485 (X.27), power consumption from 5 V, max.		300 mA
● RS 232C (V.24), power consumption from 5 V, max.		300 mA
Memory
Memory requirements per interface in memory card of S7-CPU		1 to 5 KB for parameters; 0 to 55 KB for message texts; 0 to 64 KB for loadable drivers
Interfaces
Interface physics, 20 mA (TTY)		Yes
Interface physics, RS 232C (V.24)		Yes
Interface physics, RS 422/RS 485 (X.27)		Yes
20 mA (TTY), cable length shielded, max.		1 000 m
RS 232, cable length shielded, max.		10 m
RS 422/485, cable length shielded, max.		1 200 m
Point-to-point
● Transmission rate, max.		115.2 kbit/s; distributed on both interfaces
● supported printers		HP-Deskjet, HP-Laserjet, IBM-Proprinter, user-defined
Integrated protocol driver
— 3964 (R)		Yes
— ASCII		Yes
— RK512		Yes
— Printer		Yes
— customer-specific drivers reloadable		Yes
Transmission rate, 20 mA (TTY)
— with 3964 (R) protocol, max.		19.2 kbit/s
— with ASCII protocol, max.		19.2 kbit/s
— with printer driver, max.		19.2 kbit/s
— with RK 512 protocol, max.		19.2 kbit/s
Transmission rate, RS 422/485
— with 3964 (R) protocol, max.		115.2 kbit/s
— with ASCII protocol, max.		115.2 kbit/s
— with printer driver, max.		115.2 kbit/s
— with RK 512 protocol, max.		115.2 kbit/s
Transmission rate, RS232
— with 3964 (R) protocol, max.		115.2 kbit/s
— with ASCII protocol, max.		115.2 kbit/s
— with printer driver, max.		115.2 kbit/s
— with RK 512 protocol, max.		115.2 kbit/s
Communication functions
S7 communication
● S7 extended communication		Yes
Number of connections
● overall		8
Configuration
Configuration software
● STEP 7		Yes; own parameter assignment forms
Dimensions
Width		25 mm
Height		290 mm
Depth		210 mm
Weights
Weight, approx.		720 g; Interface module: 100 g
last modified:		31.07.2014
