6AV8101-0BB00-0BA1 SCD 1297-ET, 12

6AV8101-0BB00-0BA1 SCD 1297-ET, 12" LCD MONITOR

Product Code: 6AV8101-0BB00-0BA1

Availability: In Stock

Price: $1,370.00
Qty:
Add to Wish List
Add to Compare
Artikelnummer 6AV8101-0BB00-0BA1
SCD 1297-ET, 12" LCD MONITOR WITH RESISTIVE TOUCH, FLUSH-MOUNT. IND., UL1950/IP54, OPT. RESOLUTION: 800X600, 30-97 KHZ, SCALING DSP, COLOR TFT PANEL, ON-SCREEN CONTROLS, 230V AC POWER UNIT, CONNECTING CABLE 1.8 M
Display
Design of display 12" TFT
Screen diagonal 12 in
visible area (HxV) in mm 246 x 184
Viewing angle 120° x 100°
On Screen Display (OSD) configuration Yes
Number of colors (bit levels) 256k
Pixel pitch 0.31 x 0.31
Resolution (pixels)
● Horizontal image resolution 800
● Vertical image resolution 600
General features
● Mains switch No
● Detachable from computer unit 1.8 to 20m
● Display Full screen
● Image refresh rate 50 - 72 Hz
— Refresh rate, min. 50 Hz
— Max. image refresh rate 72 Hz
● Image refresh rate 30 - 80 KHz
— Image line frequency, min. 30 kHz
— Image line frequency, max. 80 kHz
● Contrast 300 cd/m² / 300:1
Control elements
Function keys No
Membrane keyboard & Piezo mouse No
Supply voltage
Line frequency
● Line frequency 47 bis 63 Hz
Interfaces
PS/2 interfaces for keyboard & mouse No
Video interfaces
● analog video signal (VGA) Yes
Touch interfaces
● serial interface for touch screen Optional
Degree and class of protection
Degree of protection to EN 60529 IP65
IP (at the front) 65
Standards, approvals, certificates
EMC CE (industry)
Ambient conditions
Operating temperature
● Ambient temperature in operation 0 to +40°C
— during operating phase, minimum 0 °C
— during operating phase, maximum 40 °C
Vibrations
● Vibration load in operation 1g (10m/s²)
Shock testing
● Shock loading in operation 5g (50m/s²)
Dimensions
Width of the housing front 364 mm
Height of housing front 284 mm
Device depth 76 mm
last modified: 14.10.2014
