6AV7844-.....-0..0 SIMATIC PANEL PC 477, 15

6AV7844-.....-0..0 SIMATIC PANEL PC 477, 15" KEY

Product Code: 6AV7844-.....-0..0

Availability: In Stock

Price: $2,157.75
Qty:
Add to Wish List
Add to Compare
Artikelnummer 6AV7844-.....-0..0
SIMATIC PANEL PC 477 15" KEY DISPLAY, 1024 X 768;
General information
Warranty 24 months liability for defects
Operator control and monitoring
Accessory components Slide-in keyboard labels
Display
Screen diagonal 15 in
Size 15.1" TFT
Resolution (pixels)
● Resolution (WxH in pixel) 1024 x 768
General features
● Front panel 15" TFT display
Backlighting
● MTBF backlighting (at 25 °C) 50 000 h
Control elements
Function keys 36
Mouse, at front Yes
Touch operation
● Design as touch screen No
Installation type/mounting
central design Yes
Distributed design No
Supply voltage
Line frequency
● Line frequency 50 / 60 Hz
Power losses
Power loss in full configuration 24V DC: 85 W max., 230V AC: 85 W max. (3 W included per slot)
Processor
Processor type Intel Pentium III Technology; Intel Celeron 650 MHz, Intel Pentium III 933 MHz
Drives
Diskette drive optional: via external USB floppy disk drive
Optical drives possible as external drive via USB
Hard disk Compact Flash Drive, 512 MB or 1GB
Memory
Type of memory SDRAM-133
Main memory 512 Mbyte
● Capacity of main memory, maximum 512 Mbyte
Interfaces
PROFIBUS/MPI Optionally onboard, isolated, max. 12 Mbit/s, no plug-in card necessary, CP5611-compatible
USB port 1 x on front, 2 x on rear, USB 2.0 (500 mA)
Free slots 3x PC104+ (via spec. expansion rack)
Number of compact flash slots 1
Connection for keyboard/mouse USB / USB
serial interface COM1: 1 x V.24 (RS232)
Video interfaces
● Graphics interface DVI-I usable for additional display unit (VGA via adapter); color depth 16 bits, video memory up to 32 MB, resolution in each case as integrated display
Industrial Ethernet
● Industrial Ethernet interface Onboard, 2 x 10/100 Mbit/s, RJ45, no plug-in card necessary
— 100 Mbps Yes
— 1000 Mbps No
Monitoring functions
Temperature Yes
Watchdog Yes
Status LEDs No
Degree and class of protection
IP (at the front) 65
Standards, approvals, certificates
Approval CE, cULus (508)
CE mark Yes
EMC CE, EN 55011, EN 61000-6-4, EN 61000-6-2
EN 61000-6-2 Yes
Marine approval
● Germanischer Lloyd (GL) No
● American Bureau of Shipping (ABS) No
● Bureau Veritas (BV) No
● Det Norske Veritas (DNV) No
● Lloyds Register of Shipping (LRS) No
● Polski Rejestr Statkow (PRS) No
Ambient conditions
maximum permissible installation angle +/- 35° opposite the vertical
Operating temperature
● Ambient temperature in operation +5 °C to +45 °C with full configuration; fanless
— during operating phase, minimum 5 °C
— during operating phase, maximum 45 °C
Relative humidity
● Relative humidity Tested to DIN IEC 60068-2-3, DIN IEC 60068-2-30, DIN IEC 60068-2-56: 5% to 80% at 25 °C (no condensation)
Vibrations
● Vibration load in operation Tested to DIN IEC 60068-2-6: 10 Hz to 58 Hz: 0.075 mm, 58 Hz to 200 Hz: 9.8 m/s² (1 g)
Shock testing
● Shock loading in operation Tested to DIN IEC 60068-2-29: 50 m/s² (5g), 30 ms, 100 shocks
Operating systems
Operating system Windows XP Embedded
Additional info on operating system Language: EN
Pre-installed operating system Yes
● Windows XP Prof. No
without operating system No
Software
SIMATIC Software Optionally with pre-installed software bundle SIMATIC WinCC flexible or WinCC flexible / WinAC RTX
Weights
Panel PC in central design, approx. 8.7 kg
last modified: 14.10.2014
