6AV7832-0BA10-1CC0 SIMATIC PANEL PC 577B, 15" TOUCH

Product Code: 6AV7832-0BA10-1CC0

Availability: In Stock

Price: $2,116.65

Qty:

Artikelnummer

6AV7832-0BA10-1CC0

		SIMATIC PANEL PC 577B 15" TOUCH; 1024X768; WINDOWS XP PROF MUI; AC 110/230V NAMUR; CEL M 440, 1,86 GHZ, 1MB L2; 1 GB RAM DDR2; 160GB SATA HDD 3,5"; DVD+/-R+/-RW; INTERFACES: 2X PCI, 2X ETHERNET 1GBIT/S, 4X USB 2.0 500MA, 1X FRONT-USB 2.0 500MA, 1X SERIAL (COM1) POWER CORD EU AND US INCLUDED
Operator control and monitoring
Accessory components		Touch protective foil (not for Inox front)
Display
Screen diagonal		15 in
Size		15" TFT Touch
Resolution (pixels)
● Resolution (WxH in pixel)		1024 x 768
General features
● Front panel		15" TFT Touch
● Expansion components		Uninterruptible power supply (USP), SIMATIC NET communication modules
Backlighting
● MTBF backlighting (at 25 °C)		50 000 h
Control elements
Function keys		No
Mouse, at front		No
Touch operation
● Design as touch screen		Yes
Installation type/mounting
central design		Yes
Distributed design		No
Power losses
Power loss in full configuration		140 W max. (17.5 W included per slot)
Dimensions
Mounting cutout/device depth (W x H x T)		450x290 / 142 (incl. optical drive)
additional mounting depth (optical drive)		21 mm
Weights
Panel PC in central design, approx.		14 kg
last modified:		14.10.2014
