6AV7811-.....-.A.0 SIMATIC PANEL PC 877, 12

6AV7811-.....-.A.0 SIMATIC PANEL PC 877, 12" KEY

Product Code: 6AV7811-.....-.A.0

Availability: In Stock

Price: $-685,000,000.00
Qty:
Add to Wish List
Add to Compare
Artikelnummer 6AV7811-.....-.A.0
SIMATIC PANEL PC 877 12" KEY, 800X600;
General information
Warranty 24 months liability for defects
Operator control and monitoring
Accessory components Slide-in keyboard labels, direct key module, remote kit
Display
Screen diagonal 12 in
Size 12.1" TFT
Resolution (pixels)
● Resolution (WxH in pixel) 800 x 600
General features
● Front panel 12" TFT Key
● Expansion components Uninterruptible power supply (USP), SIMATIC NET communication modules
Backlighting
● MTBF backlighting (at 25 °C) 50 000 h
Control elements
Function keys 36 with LEDs
Mouse, at front Yes
Touch operation
● Design as touch screen No
Installation type/mounting
central design Yes
Distributed design Yes; by means of remote kit
Supply voltage
Line frequency
● Line frequency 50 / 60 Hz
Power losses
Power loss in full configuration 24V DC: 230 W max., 230V AC: 300 W max. (10 W included per slot)
Processor
Processor type Intel Pentium 4 technology; Intel Celeron 2.0 GHz, Intel Pentium 4 2.8 GHz, Intel Pentium 4 mobile 2.2 GHz
Drives
Diskette drive 1.4 MB, on rear, can be operated from side
Optical drives optional: DVD-ROM or DVD±R±RW combi drive; on rear, can be operated from side
Hard disk 3.5" EIDE hard disk drive ≥ 40 GB, optional: 3.5" hard disk drive ≥ 80 GB, optional: 2x 2.5" hard disk module ≥ 40 GB, optional 2x 2.5" SATA-RAID1 hard disk module ≥ 60GB. All drives with vibration- and oscillation-resistant mountings.
Memory
Type of memory DDR
Main memory 256 MB to 2 GB
● Capacity of main memory, maximum 2 048 Mbyte
Interfaces
PROFIBUS/MPI onboard, electrically isolated, max. 12 Mbps, no plug-in card necessary, CP 5611-compatible
USB port 1 x on front, 2 x on rear, USB 2.0 (500 mA)
Free slots 2x PCI, 2x PCI/ISA shared, 1x ISA (slots with board retainer)
Number of PCI slots 4; 2x ISA / PCI Shared
Number of compact flash slots 0
Connection for keyboard/mouse PS/2 or USB; PS/2 or USB
serial interface COM1: 1 x V.24 (RS232), COM2: 1 x V.24 (RS232C)
parallel interface LPT1 (EPP/ECP)
Video interfaces
● Graphics interface DVI-I usable for additional display unit (VGA via adapter); color depth 16 bits, video memory up to 32 MB, resolution in each case as integrated display
Industrial Ethernet
● Industrial Ethernet interface Onboard, 1 x 10/100 Mbit/s, RJ45, no plug-in card necessary
— 100 Mbps Yes
— 1000 Mbps No
Monitoring functions
Temperature Yes
Watchdog Yes
Status LEDs Power, temperature (on front panel)
Standards, approvals, certificates
Approval CE, cULus (508)
CE mark Yes
EMC CE, EN 55011, EN 61000-6-4, EN 61000-6-2
EN 61000-6-2 Yes
Marine approval
● Germanischer Lloyd (GL) No
● American Bureau of Shipping (ABS) No
● Bureau Veritas (BV) No
● Det Norske Veritas (DNV) No
● Lloyds Register of Shipping (LRS) No
● Polski Rejestr Statkow (PRS) No
Ambient conditions
maximum permissible installation angle +/- 20°
Operating temperature
● Ambient temperature in operation In full configuration: +5°C to +45°C or +5°C to +50°C in installation space, if at front max. 40°C (only with Pentium 4 Mobile 2.2 GHz)
— during operating phase, minimum 5 °C
— during operating phase, maximum 50 °C
Relative humidity
● Relative humidity Tested to DIN IEC 60068-2-3, DIN IEC 60068-2-30, DIN IEC 60068-2-56: 5% to 80% at 25 °C (no condensation)
Vibrations
● Vibration load in operation Tested to DIN IEC 60068-2-6: 10 Hz to 58 Hz: 0.075 mm, 58 Hz to 200 Hz: 9.8 m/s² (1 g)
Shock testing
● Shock loading in operation Tested to DIN IEC 60068-2-29: 50 m/s² (5g), 30 ms, 100 shocks
Operating systems
Operating system Windows 2000 Prof. (Multi Language), Windows XP Prof. (Multi Language), opt. without operating system
Additional info on operating system Multi Language: DE, EN, IT, FR, SP, KOR, CHN (Traditional), CHN (Simplified), JPN
Pre-installed operating system Yes
● Windows XP Prof. Yes
without operating system Yes
Software
SIMATIC Software Optionally in package with SIMATIC WinCC or WinCC flexible
Dimensions
Mounting cutout/device depth (W x H x T) 450 mm x 290 mm / 209 mm (incl. optical drive)
additional mounting depth (optical drive) 20 mm
Weights
Panel PC in central design, approx. 16 kg
last modified: 14.10.2014
