6AV7821-0A..0-.A.0 SIMATIC PANEL PC 577, 12

6AV7821-0A..0-.A.0 SIMATIC PANEL PC 577, 12" KEY

Product Code: 6AV7821-0A..0-.A.0

Availability: In Stock

Price: $2,020.75
Qty:
Add to Wish List
Add to Compare
Artikelnummer 6AV7821-0A..0-.A.0
SIMATIC PANEL PC 577 12" KEY DISPLAY;
General information
Warranty 24 months liability for defects
Operator control and monitoring
Accessory components Slide-in keyboard labels
Display
Screen diagonal 12 in
Size 12.1" TFT
Resolution (pixels)
● Resolution (WxH in pixel) 800 x 600
General features
● Front panel 12" TFT display
● Expansion components SIMATIC NET communications modules
Backlighting
● MTBF backlighting (at 25 °C) 50 000 h
Control elements
Function keys 36
Mouse, at front Yes
Touch operation
● Design as touch screen No
Installation type/mounting
central design Yes
Distributed design No
Supply voltage
Line frequency
● Line frequency 50 / 60 Hz
Power losses
Power loss in full configuration Max. 190W (15W included per slot)
Processor
Processor type Intel Pentium 4 Technology; Intel Celeron 2.0 GHz, Intel Pentium 4 2.4 GHz
Drives
Diskette drive optional via external USB drive
Optical drives Optional: DVD±R±RW combi drive; on rear, can be operated from side
Hard disk 2.5" EIDE hard disk ≥ 40 GB, vibration and oscillation-resistant mounting
Memory
Type of memory DDR-400
Main memory 256 MB, 512 MB or 1 GB, max. 3 GB
● Capacity of main memory, maximum 3 072 Mbyte
Interfaces
PROFIBUS/MPI can be implemented with plug-in card
USB port 1x at front, 4x at rear, USB 2.0 (500 mA)
Free slots 3x PCI (slot with board retainer)
Number of PCI slots 3
Number of compact flash slots 0
Connection for keyboard/mouse PS/2 or USB; PS/2 or USB
serial interface COM1: 1 x V.24 (RS232)
parallel interface LPT1 (EPP/ECP)
Video interfaces
● Graphics interface VGA interface can be used for additional display unit; color depth 32 bit, 8-128 MB shared memory
Industrial Ethernet
● Industrial Ethernet interface Onboard, 10/100/1000 Mbit/s, RJ45, no plug-in card necessary
— 100 Mbps Yes
— 1000 Mbps Yes
Monitoring functions
Temperature Yes
Watchdog Yes
Status LEDs No
Degree and class of protection
IP (at the front) 65
Standards, approvals, certificates
Approval CE, cULus (508), C-Tick
CE mark Yes
EMC CE, EN 55011, EN 61000-6-4, EN 61000-6-2
EN 61000-6-2 Yes
Marine approval
● Germanischer Lloyd (GL) No
● American Bureau of Shipping (ABS) No
● Bureau Veritas (BV) No
● Det Norske Veritas (DNV) No
● Lloyds Register of Shipping (LRS) No
● Polski Rejestr Statkow (PRS) No
Ambient conditions
maximum permissible installation angle +/- 5° opposed to vertical
Operating temperature
● Ambient temperature in operation +5 °C to +45 °C with full configuration
— during operating phase, minimum 5 °C
— during operating phase, maximum 45 °C
Relative humidity
● Relative humidity Tested to DIN IEC 60068-2-3, DIN IEC 60068-2-30, DIN IEC 60068-2-56: 5% to 80% at 25 °C (no condensation)
Vibrations
● Vibration load in operation Tested to DIN IEC 60068-2-6: 20 Hz to 58 Hz: 0.0185 mm, 58 Hz to 200 Hz: 2.5 m/s² (0.25g)
Shock testing
● Shock loading in operation Tested to DIN IEC 60068-2-29: 10 m/s² (1g), 30 ms, 100 shocks
Operating systems
Operating system Windows 2000 Prof. (Multi Language), Windows XP Prof. (Multi Language), opt. without operating system
Additional info on operating system Multi Language: DE, EN, IT, FR, SP, KOR, CHN (Traditional), CHN (Simplified), JPN
Pre-installed operating system Yes
● Windows XP Prof. Yes
without operating system Yes
Software
SIMATIC Software Optionally in package with SIMATIC WinCC or WinCC flexible
Dimensions
additional mounting depth (optical drive) 27 mm
Weights
Panel PC in central design, approx. 12 kg
last modified: 14.10.2014
